Digital Oscilloscopes
SIGLENT oscilloscopes provide the perfect balance between features and price. With bandwidths from 50 MHz to 2 GHz, low noise vertical scales down to 500 uV/div, and features like serial decoding, sequence function, Eye diagram / Jitter analysis and MSO capabilities, SIGLENT will quickly become your scope of choice.
Comparison
Model
Bandwidth
Channel
Sampling Rate
Waveform Update Rate
Memory Depth
Comparison
0
/
3
SDS6000A
500 MHz,1 GHz,2 GHz
4 + EXT
5 GSa/s (10 GSa/s ESR) per channel
170,000 wfm/s (normal mode), 750,000 wfm/s (sequence mode)
500 Mpts
Comparison
0
/
3
SDS6000L
500 MHz,1 GHz,2 GHz
8/4 + EXT
5 GSa/s (10 GSa/s ESR) per channel
170,000 wfm/s (normal mode), 750,000 wfm/s (sequence mode)
500 Mpts
Comparison
0
/
3
SDS5000X
350 MHz,500 MHz,1 GHz
2/4 + EXT
5 GSa/s (single-channel), 2.5 GSa/s (dual-channel)
110,000 wfm/s (normal mode), 500,000 wfm/s (sequence mode)
250 Mpts (single-channel), 125 Mpts (dual-channel)
Comparison
0
/
3
SDS2000X HD
100MHz, 200MHz, 350MHz
4 + EXT
2 GSa/s (interleaving mode）
Normal mode： 100,000 wfm/s;Sequence mode： 500,000 wfm/s
200 Mpts/ch (interleaving mode)
Comparison
0
/
3
SDS2000X Plus
100 MHz,200 MHz,350 MHz
2/4 + EXT
2 GSa/s
500,000 wfm/s
200 Mpts/ch
Comparison
0
/
3
SDS2000X (Discontinued)
70 MHz,100 MHz,200 MHz,300 MHz
2/4 + EXT
2 GSa/s (single-channel), 1 GSa/s (dual-channel)
140,000 wfm/s (normal mode), and 500,000 wfm/s (sequence mode)
140 Mpts (single-channel), 70 Mpts (dual-channel)
Comparison
0
/
3
SDS2000X-E
200 MHz,350 MHz
2 + EXT
2 GSa/s
110,000 wfm/s (normal mode),400,000 wfm/s (sequence mode)
28 Mpts (single-channel),14 Mpts (dual-channel)
Comparison
0
/
3
SDS1000X/X+ (Discontinued)
100 MHz,200 MHz
2 + EXT
1 GSa/s
60,000 wfm/s (normal mode), 400,000 wfm/s (sequence mode)
14 Mpts (single-channel),7 Mpts (dual-channel)
Comparison
0
/
3
SDS1000X-E
100 MHz,200 MHz
2 CH + EXT / 4 CH
1 GSa/s
100,000 wfm/s (normal mode),400,000 wfm/s (sequence mode)
14 Mpts (single-channel), 7 Mpts (dual-channel)
Comparison
0
/
3
SDS1000X-U
100 MHz
4 CH
1 GSa/s
4 00,000 wfm/s (Sequence mode)
14 Mpts
Comparison
0
/
3
SDS1000CFL (Discontinued)
70 MHz,100 MHz,200 MHz, 300 MHz
2/4 + EXT
2 GSa/s (sigle-channel), 1 GSa/s(dual-channel)
-
24 kpts (single-channel),12 kpts(dual-channel)
Comparison
0
/
3
SDS1000CML+
70 MHz, 100 MHz, 150 MHz
2 + EXT
1 GSa/s
-
2 Mpts
Comparison
0
/
3
SDS1000CNL+(Discontinued)
200 MHz
2 CH
1 GSa/s
-
40 Kpts
Comparison
0
/
3
SDS1000DL+
50 MHz
2 CH
500 MSa/s
-
32 Kpts
Options
SDS2000XP-CANFD
CAN FD trigger & decode (software)
SDS2000XP-FlexRay
FlexRay trigger & decode (software)
SDS6000Pro-FG
25 MHz waveform generator function software license ( Need to use with SAG1021I hardware)
SAG1021I
25 MHz isolated USB function/arbitrary waveform generator.
