SDG5000 Series Function/Arbitrary Waveform Generator （Discontinued）
Main Features
- Up to 160 MHz Output Frequency
- 500 MSa/S Sampling Rate
- 14-bit Vertical Resolution
- 2 Isolated/Floating Outputs
- Hardware frequency counter
- Recommended model：SDG2000X or SDG6000X
×
Two-tone testing: Building an arbitrary waveform using the Equation Draw function
Download
More
In this note, we are going to use Equation Draw within EasyWave to create a waveform that is built using the addition of sine waves with two different frequencies (700 and 1900 Hz). We will then show how to use this signal to modulate a carrier up-to 500 MHz using the other SDG output channel.
Testing Open Socket Communications Using PuTTY
Download
More
In this application note, we are going to discuss using open socket communication techniques using an open source communication tool called PuTTY with a SIGLENT SSA3032X spectrum analyzer.
